LDI Award Winning GST Acro Performer Fly Winch

LDI AWARD WINNING: Best Live Event Winch
Included: Winch, Drive Cabinet, Console, Cables, Road Cases upon Request

-Servo motor with dual encoder and redundant, manually releasable brakes that offer smooth, reliable and quiet operation
-Perfect for single point aerial performance and also customizable for a dual line system
-Zero fleet and compact design that provides flexibility and easiness for mounting and touring

Safety Features
• Dual Brakes
• Manual Release
• 10:1 Safety Factor（6mm and above）
• Real-time Load Data on Console
• Absolute Encoders
• Dual Position Encoders
• 4 Mechanical Limits
• Slack Line & Cross Groove Detection

Control Features
• Programmable Touch Screen Compact Console
• Option for Joystick Console
• Remote Troubleshooting Available (via pre-installed computer with internet access, on request)

Electrical Features
• Servo Motor Horsepower: 4.4 kw
• Motor Phase: 3 Phase + PE
• Input Voltage: 208-230VAC/380VAC, 50/60HZ

Mechanical Features
• Dimensions: W 14.8in x L 70.9in x H 14.8in (W 375mm x L 1800mm x H 375mm)
• Safe Working Load: 551lbs (250 kg and above on request)
• Variable Speed: 0-2m/s or 0-6.6ft/s（up to 3m/s or 9.8ft/s on request）
• Standard Travel: 66 ft/20m (and above on request)
• Drum Diameter: 6in /156mm and above on customization
• Steel Wire Rope: 3-7mm (synthetic rope and other SWR sizes on request)
• Brake Coil: 220/380VAC-99/170VDC, customizable on request
• Self-Weight: 661 lbs /300 kg

Product brochure available upon request.
